Technical Data
Speaker Type
Quasi 3-Way Active Speaker
Acoustical data
Frequency Response [-10dB]
54 - 19.400 Hz
Frequency Response [- 6dB]
60 - 19.100 Hz
Max SPL
132.5 dB
HF
1" Exit CD, 1.75" v.c.
Type HF
Compression driver
Horizontal Directivity
100°
Vertical Directivity
90°
Horn
Asymmetrical Horn
LF
2x 10" Neo, 2.5" v.c.
Amplifier
Amp Technology
Digipro G2 with SMPS
Amp Class
Class D
RMS Power
1050 W (525W + 525W)
Peak Power
2100 W (1050W + 1050W)
Processor
Controller
DSP 28/56 bit
AD/DA Converter
24 bit/48 KHz
CrossOver Frequency
1260 Hz
Limiter
Peak, RMS, Thermal
Advanced DSP Functions
Linear Phase FIR Filters
Input
Signal Input
1x Combo (XLR/Jack 6.3 mm) Line
Signal Output
1x XLR Male (True link)
Controls
Gain (rotary)
Preset (Flat, Playback, Wedge)
Preset (Flat, Playback, Wedge)
Mechanics
Housing
Polyproylene
Grille
Full grille
Handles
1 on left Side, 1 on Top
Rigging Points
2x M10 on Top + 1x M10 on Back
Pole Mount
D36 mm
Width
300 mm (11.81 in)
Height
604 mm (23.78 in)
Depth
324 mm (12.76 in)
Weight
17.2 kg (37 lbs)
